Precor Experience Series User Manual

ID Cover
3 Drive Cover Bracket
4 Nylock
®
bolts
5 Washers
6 Bolts
7 Drive Belt
Specifications
System Component Specification
Input Module Assy Fasteners 300 +/- 90 in-lbs (34 +/- 10 Nm)
Procedure
Review entire procedure before starting.
Removal Instructions
1. Remove the Drive Access Panel, see "Drive Access Panel Replacement" on page83.
2. Remove the left and right Drive DiskCovers, see "Drive Disk Covers Replacement" on
page84.
3. Remove the left and right Drive Housing covers (includes removing the Stairarms from
the Input Drive Crank), see "Drive Housing Covers Replacement" on page88.
4. Remove the Input Drive belt, see "Drive Belt Replacement (single stage drive)" on
page103.
5.
Use a 5/16" box end wrench to remove the four bolts and remove the drive cover
bracket from the Input Drive Assy . Retain part(s) and/or fastener(s) for install-
ation.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 150
6 Replacement Procedures
Input Drive Assembly Replacement
