l Session program.
l Session total time, including cool-down time.
l Session total distance, including horizontal, vertical, strides, revolutions, equivalent dis-
tances, etc.
l Session total calories.
l Average speed.
l Average heart rate, max heart rate, and total time spent in a heart rate zone.
l Weight, age, gender, target heart rate, parameters related to interval course profile, and
fitness score.
System Component Overview
The EFX600-18 is comprised of two basic system blocks, the console and the base. The con-
sole contains the upper control board (LPCA) and provides the user input controls, metric indic-
ator displays, and console-to-base communication interfaces. The console also provides the
standard service software menus and the error code data received from the base Lower
PCA
1
board (LPCA). The base LPCA receives machine operating commands and executes
them. The main base electrical systems include the MCU
2
(contains the LPCA), battery, the
lift motor, and Input module (contains the generator and brake system).The base also mon-
itors error conditions and sends detected error code data to the console.
Note that The EFX600 elliptical can be installed with either a single stage hybrid or a dual
stage Input drive system.
1
Lower printed circuit assembly; generally this refers to the lower board. On treadmills, this is
the motor controller unit (MCU), and on self-powered units, it is the main board in the lower
section.
2
Motor controller or motor controller module
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 221
9 Electrical Systems
System Component Overview
