Pos. Fault log (B.10)* Pos. Warning symbols display (B.20)
1 Electronics box (TTC94, TTC48-1, etc.) 1 Error warning lamp (red)
2 Pin number or error code for electronics
boxes / ADM / Eaton
2 Watchdog error warning lamp
3 Cause (value too high or too low, etc.) 3 Automatic braking function warning lamp
(red)
4 Current value 4 Electronic control unit error warning lamp
(red)
5 Time of the error 5 Driver's cab warning buzzer indicator lamp
(white)
6 How long is (was) the error active 6 Operational readiness of the attachments
warning lamp
7 How often has the error occurred 7 Warning lamp: insufficient hydraulic fluid
level (red)
8 Error code list (which day) 8 Hydraulic fluid filter clogged warning lamp
(red)
9 Error code list (which month) 9 Hydraulic fluid temperature too high warn-
ing lamp (red)
10 Error code list (which year) 10 Warning buzzer indicator lamp (white)
11 Error code list (which page) 11 Parking brake warning lamp (red)
* The Eaton and ADM errors are also dis-
played on this page.
13 Warning lamp: insufficient coolant level
(red)
14 Coolant temperature too high warning lamp
(red)
15 Warning lamp: insufficient engine oil pres-
sure (red)
16 Intake air temperature too high warning
lamp (red)
17 Air filter clogged warning lamp (red)
18 Battery and charge indicator indicator lamp
(yellow)
19 Restore snow groomer standby indicator
lamp - activate parking brake
20 Restore snow groomer standby indicator
lamp - close doors
21 Restore snow groomer standby indicator
lamp - lock driver's cab
22 Restore snow groomer standby indicator
lamp - set the engine potentiometer to Min.
23 Restore snow groomer standby indicator
lamp
- move control lever to neutral posi-
tion
24 Restore snow groomer standby indicator
lamp - set the winch potentiometer to Min.
25 Warning lamp, error CAN 0 (red)
26 Warning lamp, error CAN 1 (red)
27 Warning lamp, error CAN 2 (red)
28 Warning lamp, error CAN 3 (red)
30 Reduced vehicle speed indicator lamp
Operating and Maintenance Manual
Snow groomer BISON
88 (255)
6 - Display
BISON 908930245 - 30367
