Figure 44: Connection CAN 1 (B.70) || Connection CAN 3 (B.90)
Pos. Connection CAN 1 (B.70) Pos. Connection CAN 3 (B.90)
TTC94 Master TTC94 Master
Keyb 1 Keyboard 1 CAT_ECU1 Engine electronics
Keyb 2 Keyboard 2
ECU Engine electronics (at the accessory
support frame)
Incl
Frame
CAN Inclinometer vehicle
Incl
blade
CAN Inclinometer blade
Joystick
TTC37X Extension board
Vision Display (indicator)
Figure 45: Input / output TTC94 (B.100) || Input / output TTC48-1 (B.110)
Pos. Input / output TTC94 (B.100) Pos. Input / output TTC48-1 (B.110)
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
6 - Display
