5–61Replacement Procedures
8032
Microcontroller
RSP
= Ribbon/Shuttle Processor
LEGEND
ASIC =
Application–Specific Integrated Circuit
RSP PROM
150846
Hammer Driver
ASIC
Mech. Driver ASIC
J5
J6
Figure 5–25 . PROMs and Chips on the Mechanism Driver
