Printronix P4280 - Ham. Coil Short *

3–7Troubleshooting
Ham. Coil Short *
Instruction Indication Yes No
1. Set power switch to O (off).
Wait 15 seconds. Set power
switch to 1 (on).
“Ham. Coil Short * ” message. Step 2. Return printer to
normal operation.
2. Press the CLEAR switch.
“Ham. Coil Short * ” message. Step 3. Return printer to
normal operation.
3. Run a diagnostic self–test
(page 3–27).
“Ham. Coil Short * ” message. Step 4. Return printer to
normal operation.
4. Remove the shuttle cover
(page 5–24).
—
Step 5.
—
5. Install a magnet across the
hole in the base casting
where the cover open sensor
is mounted.
—
Step 6.
—
6. Disconnect the hammer bank
flex circuit cables from the
connectors on the base
casting.
—
Step 7.
—
7. Run a diagnostic self–test
(page 3–27).
“Ham. Coil Short * ” message. Replace the
mechanism driver
PCBA (page
5–48) then go to
step 8.
Replace the
shuttle frame
assembly (page
5–72).
8. Run a diagnostic self–test
(page 3–27).
“Ham. Coil Short * ” message. Replace both
hammer bank
cable assemblies
(page 5–8).
Return printer to
normal operation.
