Printronix P4280 - Platen Gap Adjustment

4–15Adjustment Procedures
1
1. Forms Thickness Lever
2. Feeler Gauge (0.010 inch)
3. Hammer Bank Cover Plate
4. Ribbon Mask
5. Set Screw, 3/32 inch hex (2)
3
4
2
NOTE: Left side adjustment
shown. Right side is
the same.
5
3/32 inch hex
Figure 4–7 . Platen Gap Adjustment
