5–80 Replacement Procedures
Switch Assembly, Cover Open (Figure 5–34 )
Removal
1. Prepare the printer for maintenance (page 5–3).
2. Open the printer cover.
3. Remove the shuttle cover assembly (page 5–24).
4. Remove two screws (1), if present, and lift or pry the cover open switch
assembly (2) out of the base casting.
5. Disconnect the switch connectors from intermediate cable assembly
connector CO+ (3) and CO– (4).
Installation
1. Connect the switch connectors to intermediate cable assembly connector
CO+ (3) and CO– (4).
2. Position the cover open switch assembly (2) in the base casting and
install two screws (1). (Refer to the NOTE on Figure 5–34 .)
3. Install the shuttle cover assembly (page 5–24).
4. Return the printer to normal operation (page 5–86).
