Printronix P4280 - Page 262

D–16 Wire Data
Cable No. Part No. Description
W6 150376–001 Wire Harness, Main, P4280
PFM (P)
RGR (J)
RMR (P)
RML (P)
SHM (J)
RGL (J)
PLM (P)
CCF (P)
EXF (P)
SHH (J)
MPU (J)
HBF (P)
9 PIN
9 PIN
9 PIN
9 PIN
3 PIN
9 PIN
9 PIN
3 PIN
3 PIN
3 PIN
3 PIN
3 PIN
M/H
