4–13Adjustment Procedures
1. Forms Thickness Lever
2. Platen Angle Adjustment Tool (P/N 996146–001)
3. Platen
4. Clamp Screw
5. Setscrew
2
5
4
1
3
Figure 4–6 . Platen Angle Adjustment
