4–19Adjustment Procedures
1. Right Hub
2. Screw, Left Ribbon Guide Skid (2)
3. Ribbon
4. Ribbon Guide, Left
5. Screw, Retaining (2)
6.
Left Spool
7. Ribbon Guide, Right
6
2
3
3
4
5
7
1
Figure 4–9 . Ribbon Guide Alignment
