ProMinent delta DLTa optoDrive - Material, electrical, and temperature data

16.4 Material data
Version Dosing head Suction/discharge
connector
Seals Valve balls
NP Clear acrylic PVDF PTFE Ceramic
PV PVDF PVDF PTFE Ceramic
SS Stainless steel 1.4404 Stainless steel 1.4404 PTFE Ceramic
Version Housing Hood Transparent cover Electronics
All Polyphenyl ether
(PPE with fibreglass)
Polyphenyl ether
(PPE with fibreglass)
Polycarbonate Electronic compo‐
nents
16.5 Electrical data
Data Value Unit
Power rating, approx. 73 W
Nominal current, approx. 0.90 ... 0.55 A
Switch on peak current, (within approx.
50 ms falling
8 ... 4 A
Fuse 1.6 AT
Fuses must have VDE, UL and CSA approvals. e.g. Series SPT, 1.6 A
supplied by Schurter Order no. 0001.2506 according to IEC Publ. 127 -
2/3.
16.6
Temperatures
Data Value Unit
Storage and transport temperature –10 ... +50 °C
Ambient temperature in operation (drive
and control):
–10 ... +45 °C
Data Value Unit
Liquid end temperature -10 ... +45 °C
* long term at max. operating pressure, dependent on ambient and feed
chemical temperatures
Material version Value Unit
NP_ 60 °C
PVT 120 °C
SST 120 °C
Liquid ends
Pump
Version: 100 - 230 V ±10 %, 50/60 Hz
Pump, compl.
Liquid end, long-term*
Liquid end, short-term*
Technical data
87
