Encode the status_type byte as follows:
Status type: 48 (manufacturer-specific)
‘Status’ specification: 1 constant
Encode the slot_number byte as follows:
Slot number: 0 (because only slot 0 is being used)
Encode the specifier byte as follows:
Status specification: 00 constant
Reserved
59 bytes subsequently remain freely available (user_data):
Errors are indicated using the user_data fields.
The user_data fields are each combined in blocks of 3 bytes and
are interpreted as follows:
1 - Services
2 - Error type
3 - Type of data access (read/write)
Up to 19 errors can thereby be indicated.
Tab. 36: User_Data
Order number Name Explanation
1 Status - see “DULCO flex Control DFXa
data objects" table
11 Start/Stop Complies with Start/Stop switch;
If Start/Stop = 0, then the pump is
stopped
12 Reset Clear internal pump memory and
pending errors by changing "1" to
"0"
21 Target operating mode - see “DULCO flex Control DFXa
data objects" table
22 Actual operating mode - see “DULCO flex Control DFXa
data objects" table
31 Target capacity Setpoint capacity in [l/h]
32 Actual capacity Actual capacity value in [l/h]
41 Max. metering capacity Maximum capacity in [l/h]
51 Volume per contact "batch mode" Volume to be delivered with con‐
tact in batch mode
user_data
Supplementary operating instructions for PROFIBUS
®
58
