5 Assembly and installation
n User qualification, mechanical instal‐
lation: trained qualified personnel, see
Ä Chapter 3.4 ‘Users' qualifications’
on page 14
n User qualification, electrical installa‐
tion: Electrical technician, see
Ä Chapter 3.4 ‘Users' qualifications’
on page 14
CAUTION!
Possible consequence: Material
damage.
The hinge between the front and rear
part of the housing cannot absorb
high levels of mechanical loading.
When working on the controller, hold
the top part of the controller housing
firmly.
NOTICE!
Mounting position and conditions
– Only carry out the (electrical)
installation after the (mechanical)
installation
– Ensure that there is unimpeded
access for operation
– Ensure safe and low-vibration
fixing
– Avoid direct sunlight
– Permissible ambient temperature
of the controller at the installation
site: - 10 ... 60 ℃ at max. 95%
relative air humidity (non-con‐
densing)
– Take into consideration the per‐
missible ambient temperature of
the sensors connected and other
components
Read-off and operating position
–
Install the device in a favourable
position for reading and operating
(preferably at eye level)
Mounting position
–
Leave sufficient clearance for the
cables
