ProMinent DULCOMETER Compact - Cable Cross-Sections and Cable End Sleeves; Electrical Connection of the Conductivity Sensor

5.3.1 Cable Cross-Sections and Cable End Sleeves
Minimum cross-sec‐
tion
Maximum cross-
section
Stripped insulation
length
Without cable end
sleeve
0.25 mm
2
1.5 mm
2
Cable end sleeve
without insulation
0.20 mm
2
1.0 mm
2
8 - 9 mm
Cable end sleeve
with insulation
0.20 mm
2
1.0 mm
2
10 - 11 mm
5.3.2 Electrical connection of the
conductivity sensor
CAUTION!
Length of the sensor cable
The sensor is supplied with a fixed
cable or a measuring line.
Possible consequence: Slight or
minor injuries. Material damage.
Modification of the cable (lengthening,
shortening, etc.) is prohibited.
All conductivity sensors connected to
the controller should have a shielded
sensor cable.
Assembly and installation
31
