7 Commissioning
n User qualification: trained user, see
Ä Chapter 3.4 ‘Users' qualifications’
on page 14
WARNING!
Sensor run-in periods
This can result in hazardous incorrect
metering
– Correct measuring and metering
is only possible if the sensor is
working perfectly
– Observe the sensor's operating
instructions
– Calibrate the sensor after com‐
missioning
Following mechanical and electrical instal‐
lation, integrated the controller into the
measuring point.
7.1 Initial commissioning
The controller is in STOP state when the
controller is first switched on.
Setting the auto-ranging profile
1. Select the conductive conductivity
sensor used.
2. Enter the actual sensor cable
length.
ð
Subsequently the control set‐
ting and the setting of the dif‐
ferent parameters dependent
on the process to be measured.
3. When connecting external sensors,
[INPUT > SENSOR > MANUAL]
,
adjust the auto-ranging profile, see
Ä ‘Using external sensors’
on page 46
7.2 Setting the control during
commissioning
NOTICE!
Reset to factory settings
When switching over the metering
direction, all actuators in the controller
are reset to the factory settings for the
selected metering direction.
For safety reasons, all the actuators
are deactivated. The basic load is
reset to 0 %. All parameters relating
to the actuator, are reset to the fac‐
tory setting.
Reset all the parameters that relate to
the actuator.
Commissioning
43
