SmartStor NAS User Manual
2. Carefully lay the disk drive into the drive tray, so that the screw
holes on the sides of the carrier align with the screw holes in the
drive.
3. Insert the screws through the holes in the drive carrier and into the
sides of the disk drive.
Install only the counter-sink screws supplied with the
SmartStor.
Install four screws per drive.
Snug each screw. Be careful not to over-tighten.
12
