Promise Technology SmartStor NS4700 User Manual

SmartStor NAS User Manual
3.3.6 Network
Click Device tab > Network to display the networking information of the
system. Networking information includes:
− ID
− DHCP
− IP Address
− Gateway IP Address
− Speed
− MTU
− Link
Changing Networking Configuration
1. Click Device tab > Network.
2. Move your mouse over the network you want and click the TCP/IP (or
IPV6) button.
3. Complete the required settings in the dialog window, and then click the
Submit button.
− Network Speed – Select the networking speed from the menu.
− IP Properties
− IP Address
− Subnet Mask
− Gateway IP Address
− DNS Server IP Address
− Secondary DNS Server IP Address
Click the
button to close the dialog window.
32

Promise Technology SmartStor NS4700 Specifications

General

Brand	Promise Technology
Model	SmartStor NS4700
Category	Network Storage Server
Language	English
