SmartStor NAS User Manual
2.6 Using LCD
The SmartStor provides you with a LCD on the front panel that allows
you to easily monitor the system status, and configure the network.
Figure 5. LCD panel
Select Button
Enter Button
• To monitor the system status, press the Select button repeatedly.
The system status will be displayed on the LCD panel sequentially,
including the system temperature, voltage, ventilator status, firmware
& BIOS version, etc.
• To configure the networking settings:
1. Press the Enter button to display the Network Setup option on
the LCD.
2. Press the Select Button to select the options and then press the
Enter button to change the setting values.
3. When done, select OK and press the Enter button to apply the
networking configuration.
16
