Vess A3340
Form factor 2U, 19” rack mount or desktop
Function NVR server
Operating system Windows
Drives supported Eight 3.5” SATA (3Gb/s or 6Gb/s)
Storage Expansion
(iSCSI & JBOD)
Up to 128 HD
RAID support 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60
RAID stripe size 64K, 128K, 256K, 512K, 1MB
Max. LUNs 256/system 32/array
Hot swap drives Yes
Controller Single
Graphics Intel® HD 5300
Memory 8GB DDR
Processor Intel® Xeon E3-1275 v5 Quad-core 8-thread
PSU 350W
System fans Redundant fan
Dimensions 88.2 x 446 x 410 mm
Weight
7.38 kg (16.23 lbs) w/o drives
12.9 kg (28.38 lbs) w/drives
specIfIcAtIons
2
Vess A Class NVR Storage Appliance Promise Technology
