3. Pull back
2. Slide
1. Unlock
Caution
The Vess supports disk drive hot-swapping. To avoid hand contact with an
electrical hazard, do not remove more than one drive carrier a time.
remove SecurIty cover
To remove the security cover:
1. Use the tubular key to unlock the cover. Turn counterclockwise to unlock.
2. Slide the cover to the right about 4 mm.
3. Pull the cover straight back to remove. Be careful not to drop the cover.
17
Hardware SetupVess A3340 Product Manual
