MAnAgIng logIcAl drIVes (clu)
Logical drive management includes:
• “Creating a Logical Drive (CLU)” on page 66
• “Deleting a Logical Drive (CLU)” on page 68
• “Viewing the Logical Drive Check Table (CLU)” on page 70
• “Making Logical Drive Settings (CLU)” on page 70
• “Initializing a Logical Drive (CLU)” on page 71
• “Running Redundancy Check (CLU)” on page 72
• “Locating a Logical Drive (CLU)” on page 72
Creating a Logical Drive (CLU)
You can create logical drives on existing disk arrays if there is available space in the array.
To create a logical drive from an existing disk array:
1. Main Menu >> Disk Array Management
2. Highlight the disk array in which you want to create a logical drive and press Enter.
3. Logical Drives in the Disk Array >> Create New Logical Drive
The Disk Array ID number and Maximum capacity available for the new logical drive are
displayed.
4. Highlight the following parameters and press the backspace key to erase the current value:
• Alias – Type an alias into the eld, if desired. Maximum of 32
characters (letters, numbers, spaces and underscore).
• RAID Level - Press the spacebar to toggle though a list of available RAID levels.
• Capacity – Maximum capacity shown. Enter a smaller capacity if desired.
66
Vess A Class NVR Storage Appliance Promise Technology
