Promise Technology Vess A3340 - Back Panel Connections

Back Panel Hardware
The backplane of the Vess A-Series enclosure provides access to the power supply, local management connection
(via USB keyboard and VGA or HDMI monitor port), iSCSI (Ethernet) data ports, and system fan.
Power insert
System fan
Ports and LEDs
See details on next page
Vess A3340 back panel view
6
Vess A Class NVR Storage Appliance Promise Technology
