TYPICAL PRODUCT PARAMETERS
Part No. 1125085 11 Pronto
®
M50
™
, M51
™
and M61
™
with SureStep
™
TYPICAL PRODUCT PARAMETERS
*NOTE: Refer to Percentage of Weight Distribution on page 22.
Footnotes:
1. Includes seating systems and accessories.
2. Range varies with battery conditions, surface terrain and operator’s weight.
MEDIUM BACK SEMI-RECLINE BACK OFFICE STYLE,
SEMI-RECLINE BACK
SEAT WIDTH RANGE: 18 inches 16 inches 18 inches 20 inches 18 inches
SEAT DEPTH:
16 - 18 inches 16 - 18 inches
18 - 20
inches 16 - 18 inches
BACK HEIGHT: 16½ inches 19 inches 23½ inches (w/ headrest)
18¾ inches (w/o headrest)
BACK ANGLE RANGE
(IN 5° INCREMENTS):
Standard - 95° to
100°
N/A N/A N/A N/A
UPHOLSTERY:
Light Grey Vinyl
Light Grey Vinyl, Grey Cloth,
Tan Vinyl
Charcoal Grey Vinyl
SEAT-TO-FLOOR
WITH FOOTBOARD:
WITH FRONT RIGGINGS:
WITH ELEVATING SEAT:
21 to 23 inches (Cushion Not Compressed)
21 to 23 inches
Seat-to-floor heights listed above and add up to 5
inches
19 to 21 inches
19 to 21 inches
Seat-to-floor heights listed
above and add up to 5
inches
OVERALL WIDTH: 25-7/8 inches (Without Joystick)
OVERALL HEIGHT: 35 to 43¾ inches 41½ inches
OVERALL LENGTH: 34 inches (With Footboard Folded)
39½ inches (With Footboard Extended)
DRIVE WHEELS/TIRES: 10 x 3-inch (Flat Free inserts)
CASTER: 6 x 2-inch Front/Rear w/Precision Sealed Bearings
FOOTRESTS/
LEGRESTS:
Flip Up, Depth and Height Adjustable, Footboard,
Swingaway Front Rigging, Elevating Legrest
WEIGHT
1
W/O BATTERIES:
W/BATTERIES (U1):
140 to 165 lbs
188 to 212 lbs
SHIPPING
BASE W/O BATTERIES:
BASE WITH BATTERIES:
MEDIUM BACK:
SEMI-RECLINE:
OFFICE STYLE:
107 lbs
154 lbs
40 lbs
64 lbs
44 lbs
ARMRESTS: Adjustable Width, Angle, Heights and Depth
BATTERIES: U1 - Quantity 2
PERFORMANCE
SPEED:
TURNING RADIUS:
RANGE (VARIABLE)
2
:
*WEIGHT LIMITATION:
0 to 4.3 m.p.h.
19½ inches
up to 12 miles
300 lbs
