SECTION 11—BATTERIES
Part No. 1125085 67 Pronto
®
M50
™
, M51
™
and M61
™
with SureStep
™
FIGURE 11.2 Removing/Installing Batteries from/into Battery Tray
Connecting/Disconnecting Battery Cables
Connecting Battery Cables
WARNING
NEVER allow any of your tools and/or battery cable(s) to contact BOTH battery
terminal(s)/post(s) at the same time. An electrical short may occur and serious
personal injury or damage may occur.
The use of rubber gloves and chemical goggles and face shield is recommended
when working with batteries.
Rear Battery
Front
Battery
RED Battery Connectors
Plug into
Controller
BLACK Battery
Connectors
Rear of
Wheelchair
Front of
Wheelchair
Wheelchair
Base Frame
Top Shroud
Battery Handle
BLACK Controller
Connector
Joystick
Cable
To Next Page
