Pronto M50 - Page 48

SECTION 7—SEAT
Pronto
®
M50
™
, M51
™
and M61
™
with SureStep
™
48 Part No. 1125085
FIGURE 7.7 Adjusting Seat Position on Seat Base
WEIGHT
LIMITATION
SEAT POST
MOUNTING HOLE
1-INCH
BACK
STANDARD 1-INCH
FORWARD
300 LBS
1 Y Y N/A
2 Y Y N/A
3 Y N/A N/A
4 Y N/A N/A
5 Y N/A N/A
220 LBS
1YYY
2 Y Y N/A
3 Y N/A N/A
4 Y N/A N/A
5 Y N/A N/A
150 LBS
1YYY
2YYY
3YYY
4YYY
5YYY
Bolts
Washers
Seat Base
Detail “A” - Seat Position
I-inch Back
Seat Position
I-inch Back
Seat Position
I-inch Back
Seat Position
Standard
Seat
Position
Standard
Seat
Position
Standard
Seat
Position
Standard
Seat
Position
Front of Seat
Rear of Seat
Seat
Assembly
I-inch
Forward
Position*
I-inch Forward
Seat Position*
I-inch Back
Seat Position
Detail “C” - Proper Seat Positions for 18-inch Deep Back Setting
Y - Use N/A - DO NOT Use
*NOTE: For users over 220 lbs - DO NOT use 1-inch
forward position.
I-inch Forward
Position*
I-inch Forward
Position*
NOTE: Office style van seat is
shown. Standard van seat
adjusts the same way.
