ProSoft Technology MVI56E-MNETC User Manual

MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform Reference
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 101 of 172
September 20, 2018
5 Reference
In This Chapter
 Product Specifications ......................................................................... 101
 Functional Overview ............................................................................ 103
 Ethernet Cable Specifications ............................................................. 134
 Modbus Protocol Specification ............................................................ 135
 Using the Optional Add-On Instruction ................................................ 148
 Adding the Module to an Existing Project ............................................ 159
 Using the Sample Program ................................................................. 162
5.1 Product Specifications
The MVI56E Modbus TCP/IP Client Enhanced Communication Module -
Client/Server allows Rockwell Automation
®
ControlLogix
®
Programmable
Automation Controllers (PACs) to interface easily with Modicon Programmable
Automation Controller (PACs) , as well as multiple Modbus TCP/IP server-
compatible instruments and devices. The multi-Client module improves
performance when controlling multiple servers on a Modbus TCP/IP network, by
supporting up to 30 Clients. It also supports up to 20 server connections (10
MNET, 10 MBAP).
MVI56E enhancements include configuration and management through the
module’s Ethernet port, and CIPconnect
®
technology for bridging though
ControlNet™ and EtherNet/IP™ networks.
5.1.1 General Specifications
 Backward compatible with previous MVI56-MNETC versions
 Single-slot 1756 ControlLogix backplane compatible
 10/100 Mbps auto crossover detection Ethernet configuration and application
port
 User-definable module data memory mapping of up to 10,000 16-bit registers
 CIPconnect-enabled network configuration and diagnostics monitoring using
ControlLogix 1756-ENxT and 1756-CNB modules and EtherNet/IP pass-
through communication
 ProSoft Configuration Builder (PCB) software supported, a Windows-based
graphical user interface providing simple product and network configuration
 Sample ladder logic and Add-On Instructions (AOI) are used for data transfer
between module and processor
 4-character, alpha-numeric, scrolling LED display of status and diagnostics
data in plain English – no cryptic error or alarm codes to decipher

ProSoft Technology MVI56E-MNETC Specifications

General

Brand	ProSoft Technology
Model	MVI56E-MNETC
Category	Server
Language	English
