MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform Start Here
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 9 of 172
September 20, 2018
1 Start Here
In This Chapter
System Requirements ........................................................................... 10
Setting Jumpers .................................................................................... 10
Installing the Module in the Rack ........................................................... 12
Creating a New RSLogix 5000 Project .................................................. 13
Connecting Your PC to the ControlLogix Processor .............................. 27
Downloading the Sample Program to the Processor ............................. 28
To get the most benefit from this User Manual, you should have the following
skills:
Rockwell Automation
®
RSLogix™ software: launch the program, configure
ladder logic, and transfer the ladder logic to the processor
Microsoft Windows
®
: install and launch programs, execute menu
commands, navigate dialog boxes, and enter data
Hardware installation and wiring: install the module, and safely connect
Modbus TCP/IP and ControlLogix devices to a power source and to the
MVI56E-MNETC/MNETCXT module’s application port(s)
