Using Controller Tags MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
User Manual Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Page 78 of 172 ProSoft Technology, Inc.
September 20, 2018
3.3.3 MNETC.STATUS
This controller tag structure contains module and Client status data. For a more
complete description of the MNETC.STATUS controller tag structure, refer to the
Status Data Definition (page 93).
Name
Data Type
Description
PassCnt
INT
Program cycle counter
ProductVersion
INT
This is used to pass the product version to
the processor
ProductCode
INT[2]
This is used to pass the product code to the
processor
BlockStats
MNETCBLOCKSTATS
Block transfer statistics
CmdBits
INT[30]
Command bits array to be used for 30
Clients
ClientStatsTrigger
BOOL
Get Client status
ClientID
INT
Client ID to get status from
ClientStatus
MNETCCLIENTSTATS[30
]
Client status data
CmdErrorList
INT[16]
Command Error List
EventSeqCmdPending
MNETCCMDCLIENTSEQ
_PENDING
Number of sequence events pending in the
module
EventSeqCmd
MNETCEVENTCMD_SE
QSTAT
Event sequence event commands pending
EventSeqReady
DINT
Status data (bit=1 data ready, bit=0 no
event data)
ServerStatus
MNETCSERVERS
Server status data
ServerStatsTrigger
BOOL
Trigger the Server Status block request
3.3.4 MNETC.UTIL
This controller tag structure stores the variables required for the data transfer
between the processor and the MVI56E-MNETC/MNETCXT module.
Name
Data Type
Description
LastRead
INT
Index of last read block
LastWrite
INT
Index of last write block
BlockIndex
INT
Computed block offset for data table
StatusIndex
INT
Computed block offset for status data
ReadDataSizeGet
INT
Gets ReadData array length
WriteDataSizeGet
INT
Gets WriteData array length
ReadDataBlkCount
INT
Holds the value of the block counts of the
ReadData array
