2.1.2 Upgrading from MVI56-MNETC in ProSoft Configuration
Builder
MVI56E-MNETC/MNETCXT modules are fully backward-compatible with MVI56-
MNETC modules. However, you will need to convert your MVI56-MNETC
configuration in ProSoft Configuration Builder to a form that your new MVI56E-
MNETC/MNETCXT module will accept when you download it.
ProSoft Configuration Builder version 2.2.2 or later has an upgrade option that
easily performs this conversion, while preserving all your configuration settings
and any name you may have given your module.
Important: For this procedure, ProSoft Configuration Builder version 2.2.2 or later must be
installed on your PC. You can download the latest version from www.prosoft-technology.com.
1 In ProSoft Configuration Builder's tree view, click the MODULE icon and right-
click to open a shortcut menu.
2 On the shortcut menu, select CHANGE MODULE TYPE TO MVI56E-MNETC.
2.1.3 Setting Up the Project
To begin, start PROSOFT CONFIGURATION BUILDER (PCB).
