1.4.1 Before You Import the Add-On Instruction
Note: This section only applies if your processor is using RSLogix 5000 version 16 or higher. If you
have an earlier version, please see Using the Sample Program (page 162).
Two Add-On Instructions are provided for the MVI56E-MNETC/MNETCXT
module. The first is required for setting up the module; the second is optional.
Download the files from www.prosoft-technology.com. Save them to a convenient
location in your PC, such as Desktop or My Documents.
File Name
Description
MVI56EMNETC_AddOn_Rung_v1_x.L5X.
A newer version may be available at:
www.prosoft-technology.com
L5X file containing Add-On Instruction,
user defined data types, controller tags and
ladder logic required to configure the
MVI56E-MNETC/MNETCXT module
MVI56EMNETC_Optional_AddOn_Rung_v1_x.L5X.
A newer version may be available at:
www.prosoft-technology.com
Optional L5X file containing additional Add-
On Instruction with logic for changing
Ethernet configuration and clock settings.
About the Optional Add-On Instruction
The Optional Add-On Instruction performs the following tasks:
 Read/Write Ethernet Configuration
Allows the processor to read or write the module IP address, subnet mask,
and network gateway IP address.
 Read/Write Module Clock Value
Allows the processor to read and write the module clock settings. The
module's free-running clock also stores the last time that the Ethernet
configuration was changed or the last time the module was restarted or
rebooted. The date and time of the last change or restart is displayed on the
scrolling LED during module power-up/start-up sequence.
For more information, see Using the Optional Add-On Instruction (page 148).
Note: You can also set the date and time from the module's web page. See Connecting to the
Module's Web Page (page 98).
Important: The Optional Add-On Instruction supports only the two features listed above. You must
use the regular MVI56E-MNETC/MNETCXT Add-On Instruction for all other features including
backplane transfer and Modbus data communication.
