MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform Reference
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 149 of 172
September 20, 2018
Note: This is an optional feature. You can perform the same task through PCB (ProSoft
Configuration Builder). Even if your PC is in a different network group you can still access the
module through PCB by setting a temporary IP address.
Read/Write Module Clock Value
Allows the processor to read and write the module clock settings. The module
clock stores the last time that the Ethernet configuration was changed. The
date and time of the last Ethernet configuration change is displayed in the
scrolling LED during module power up.
Important: The Optional Add-On Instruction only supports the two features listed above. You must
use the sample ladder logic for all other features including backplane transfer of Modbus TCP/IP
data.
