Diagnostics and Troubleshooting MVI56E-MNETC/MNETCXT ♦ ControlLogix Platform
User Manual Modbus TCP/IP Client Enhanced Communication Module - Client/Server
Page 94 of 172 ProSoft Technology, Inc.
September 20, 2018
This value is incremented each time a complete
program cycle occurs in the module.
Total number of read blocks transferred from the
module to the processor
Total number of write blocks transferred from the
processor to the module
Total number of blocks successfully parsed that were
received from the processor
Total number of Event Command blocks received from
the processor
Total number of Command Control blocks received
from the processor
Total number of block errors recognized by the module
Displays enabled or disabled status of all 16
commands in the Client x Command List for each
Client
Initiates request for Client Status block from module
when set to 1
Specifies Client (0 to 29) to request status data from
Total number of command list requests sent from
Client
Total number of command list responses received by
Client
This value is incremented each time an error message
is received from a remote unit or a local error is
generated for a command.
ClientStatus[x].Responses
ClientStatus[x].CfgErrWord
Configuration Error Word - This word contains a
bitmap that indicates general module configuration
errors.
Most recent error code recorded for the Client
Previous most recent error code recorded for the
Client
Command error code for each command (0-15) on the
specified Client's command list
EventSeqCmdPending.Trigg
er
Set to 1 to trigger the command queue status data
request.
EventSeqCmdPending.Clien
t[x]_QueueCount
Number of Event sequence commands for which
status has not yet been retrieved
EventSeqCmdPending.Clien
t[x]_WaitingMsgs
Total number of commands waiting in the command
queue
