MVI56E-MNETC/MNETCXT ControlLogix Platform Diagnostics and Troubleshooting
Modbus TCP/IP Client Enhanced Communication Module - Client/Server User Manual
ProSoft Technology, Inc. Page 97 of 172
September 20, 2018
Word Offset
Description
0
Command 0 Error
1
Command 1 Error
2
Command 2 Error
3
Command 3 Error
….
15
Command 15 Error
16
Command 16 Error
For every command that has an error, the module automatically sets the poll
delay parameter to 30 seconds. This instructs the module to wait 30 seconds
until it attempts to issue the command again.
As the commands in the Client Command Last are polled and executed, an error
value is maintained in the module for each command. This error list can be
transferred to the processor.
Standard Modbus Exception Code Errors
Code
Description
1
Illegal function
2
Illegal data address
3
Illegal data value
4
Failure in associated device
5
Acknowledge
6
Busy; message was rejected
Module Communication Error Codes
Code
Description
-2
Timeout while transmitting message
-11
Timeout waiting for response after request (same as -36)
253
Incorrect slave/server address in response
254
Incorrect function code in response
255
Invalid CRC/LRC value in response
