ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform Verify Communication
Modbus Communication Module with Reduced Data Block User Manual
ProSoft Technology, Inc. Page 105 of 223
3 Verify Communication
In This Chapter
 Verify Master Communications ............................................................ 106
 Verify Slave Communications .............................................................. 113
There are several ways to verify that the MVI56E-MCMR module is
communicating with the processor and with the Modbus network.
 View the LED Status Indicators
 View the Module Status in the RSLogix 5000 Controller Tags
 View Diagnostics in ProSoft Configuration Builder

ProSoft MVI56E-MCMR Specifications

General

Brand	ProSoft
Model	MVI56E-MCMR
Category	Control Unit
Language	English
