Start Here MVI56E-MCMR ♦ ControlLogix Platform
User Manual Modbus Communication Module with Reduced Data Block
Page 14 of 223 ProSoft Technology, Inc.
1.4 Package Contents
The following components are included with your MVI56E-MCMR module, and
are all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Modbus Communication Module with
Reduced Data Block
Cable #14, RJ45 to
DB9 Male Adapter
cable
For DB9 Connection to Module’s
Application Serial Port
Two Adapters, DB9 Female to Screw
Terminal. For RS422 or RS485
Connections to Port 1 and 2 of the Module
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
