Reference MVI56E-MCMR ♦ ControlLogix Platform
User Manual Modbus Communication Module with Reduced Data Block
Page 144 of 223 ProSoft Technology, Inc.
6.2.2 Hardware Specifications
800 mA @ 5 VDC
3 mA @ 24 VDC
0°C to 60°C (32°F to 140°F)
-40°C to 85°C (-40°F to 185°F)
30 g operational
50 g non-operational
Vibration: 5 g from 10 to 150 Hz
5% to 95% (without condensation)
Battery Status (ERR)
Application Status (APP)
Module Status (OK)
4-Character, Scrolling, Alpha-
Numeric LED Display
Shows Module, Version, IP, Port Status, P1 and
P2 Settings, and Error Information
Debug/Configuration Ethernet port (E1 - Config)
10/100 Base-T, RJ45 Connector, for CAT5 cable
Link and Activity LED indicators
Auto-crossover cable detection
Serial Application ports (P1 & P2)
Software configurable
communication parameters
Baud rate: 110 baud to 115.2 kbps
RS-232, RS-485, and RS-422
Parity: none, odd or even
Data bits: 5, 6, 7, or 8
Stop bits: 1 or 2
RTS on/off delay: 0 to 65535 milliseconds
Full hardware handshaking control (optional)
Radio and modem support
RJ45 (DB-9M with supplied adapter cable)
Configurable RS-232 hardware handshaking
500V Optical isolation from backplane
RS-232, RS-422, RS-485 jumper-select, per port
RX (Receive) and TX (Transmit) LEDs, each port
RJ45 to DB-9M cables for each serial port
