ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform Diagnostics and Troubleshooting
Modbus Communication Module with Reduced Data Block User Manual
ProSoft Technology, Inc. Page 121 of 223
5 Diagnostics and Troubleshooting
In This Chapter
 Ethernet LED Indicators ...................................................................... 122
 Using the Diagnostics Menu in ProSoft Configuration Builder ............. 124
 Reading Status Data from the Module ................................................ 135
 Communication Error Codes ............................................................... 136
The module provides information on diagnostics and troubleshooting in the
following forms:
 LED status indicators on the front of the module provide information on the
module’s status.
 Status data contained in the module can be viewed in ProSoft Configuration
Builder through the Ethernet port.
 Status data values are transferred from the module to the processor.

ProSoft MVI56E-MCMR Specifications

General

Brand	ProSoft
Model	MVI56E-MCMR
Category	Control Unit
Language	English
