ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform Reference
Modbus Communication Module with Reduced Data Block User Manual
ProSoft Technology, Inc. Page 175 of 223
6.5 MVI56E-MCMR Status Data Definition
This section contains a description of the members present in the
MCMR.STATUS object. This data is transferred from the module to the
processor in a message block.
Offset
Content
Description
0
Program Scan Count
This value is incremented each time a complete program cycle
occurs in the module.
1 to 2
Product Code
These two registers contain the product code of "MCM".
3 to 4
Product Version
These two registers contain the product version for the current
running software.
5 to 6
Operating System
These two registers contain the month and year values for the
program operating system.
7 to 8
Run Number
These two registers contain the run number value for the
currently running software.
9
Port 1 Command List
Requests
This field contains the number of requests made from this port to
Slave devices on the network.
10
Port 1 Command List
Response
This field contains the number of Slave response messages
received on the port.
11
Port 1 Command List
Errors
This field contains the number of command errors processed on
the port. These errors could be due to a bad response or
command.
12
Port 1 Requests
This field contains the total number of messages sent out of the
port.
13
Port 1 Responses
This field contains the total number of messages received on the
port.
14
Port 1 Errors Sent
This field contains the total number of message errors sent out of
the port.
15
Port 1 Errors
Received
This field contains the total number of message errors received
on the port.
16
Port 2 Command List
Requests
This field contains the number of requests made from this port to
Slave devices on the network.
17
Port 2 Command List
Response
This field contains the number of Slave response messages
received on the port.
18
Port 2 Command List
Errors
This field contains the number of command errors processed on
the port. These errors could be due to a bad response or
command.
19
Port 2 Requests
This field contains the total number of messages sent out the
port.
20
Port 2 Responses
This field contains the total number of messages received on the
port.
21
Port 2 Errors Sent
This field contains the total number of message errors sent out
the port.
22
Port 2 Errors
Received
This field contains the total number of message errors received
on the port.
23
Read Block Count
This field contains the total number of read blocks transferred
from the module to the processor.
24
Write Block Count
This field contains the total number of write blocks transferred
from the module to the processor.
25
Parse Block Count
This field contains the total number of blocks successfully parsed
that were received from the processor.
26
Command Event
Block Count
This field contains the total number of command event blocks
received from the processor.
