ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform Start Here
Modbus Communication Module with Reduced Data Block User Manual
ProSoft Technology, Inc. Page 25 of 223
1.8.3 Creating the Module in a Local Rack
Note: If you are installing the MVI56E-MCMR module in a local rack, follow these steps. If you are
installing the module in a remote rack, follow the steps in Creating the Module - Remote Rack
(page 20).
1 Add the MVI56E-MCMR module to the project.
In the CONTROLLER ORGANIZATION window, select I/O CONFIGURATION and
click the right mouse button to open a shortcut menu. On the shortcut menu,
choose NEW MODULE...
This action opens the SELECT MODULE dialog box.
