ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform Reference
Modbus Communication Module with Reduced Data Block User Manual
ProSoft Technology, Inc. Page 177 of 223
6.6 Modbus Protocol Specification
The following pages give additional reference information regarding the Modbus
protocol commands supported by the MVI56E-MCMR.
6.6.1 Commands Supported by the Module
The format of each command in the list depends on the MODBUS Function Code
being executed.
The following table lists the functions supported by the module.
Function
Code
Definition
Supported in
Master
Supported in
Slave
1
Read Coil Status
X
X
2
Read Input Status
X
X
3
Read Holding Registers
X
X
4
Read Input Registers
X
X
5
Set Single Coil
X
X
6
Single Register Write
X
X
8
Diagnostics
X
15
Multiple Coil Write
X
X
16
Multiple Register Write
X
X
17
Report Slave ID
X
22
Mask Write 4X
X
23
Read/Write
X
Each command list record has the same general format. The first part of the
record contains the information relating to the communication module and the
second part contains information required to interface to the MODBUS slave
device.
