ProSoft MVI56E-MCMR User Manual

Reference MVI56E-MCMR ♦ ControlLogix Platform
User Manual Modbus Communication Module with Reduced Data Block
Page 196 of 223 ProSoft Technology, Inc.
6.7.4 Reading the Ethernet Settings from the Module
Expand the MVI56MCMRETHERNET controller tag and move a value of 1 to
MVI56MCMRETHERNET.READ.
The bit will be automatically reset and the current Ethernet settings will be copied
to MVI56MCMRETHERNET controller tag as follows.
To check the status of the message, refer to the READETHERNETMSG tag.
