6.3 Trouble Zones
Each Protégé® SE Integrated System Controller can monitor up to 64 local trouble zones. Trouble
zones are used to monitor the status of the Protégé® SE Integrated System Controller and in most
cases not physically connected to an external zone. For example, trouble zone CP001:03 is used to
monitor the Protégé® SE Integrated System Controller’s backup baery voltage and warn the
Protégé® SE Integrated System Controller that the baery is disconnected or voltage is too low.
This can then be used to report a message to a monitoring staon, remote computer, keypad or
siren.
The following table details the trouble zones that are congured in the Protégé® SE Integrated
System Controller. The trouble type and group dene the trouble that is generated by the trouble
zone when it is acvated.
Zone Number Descripon Type Group
CP001:01 Module Tamper System Tamper System
CP001:02 AC failure Power Fault General
CP001:03 Low Baery Power Fault General
CP001:04 Real Time Clock Not Set RTC/Clock Loss General
CP001:05 Service Report Test * *
CP001:06 Service Report Failure To Communicate Reporng Failure General
CP001:07 Phone Line Fault Phone Line Lost General
CP001:08 Auxiliary Failure Power Fault General
CP001:09 Bell 1 Cut/Tamper Bell/PGM Fault General
CP001:10 Bell 2 Cut/Tamper Bell/PGM Fault General
CP001:11 Bell 1 Cut/Tamper Bell/PGM Fault General
CP001:12 Bell 2 Cut/Tamper Bell/PGM Fault General
CP001:13 Module Communicaon Module Loss System
CP001:14 Module Network Security Module Security System
CP001:15 Expansion Device Missing Hardware Fault System
CP001:16 Communicaon Port 1 Fault Hardware Fault System
CP001:17 Communicaon Port 2 Fault Hardware Fault System
CP001:18 Ethernet Hardware Fault Hardware Fault System
CP001:19 Ethernet Link Lost Hardware Fault System
CP001:20 DVAC Line Fault/Polling Error Hardware Fault System
CP001:21 ModBUS Communicaon Fault Hardware Fault System
CP001:22 Protégé® System Remote Access Hardware Fault System
CP001:23 Installer Logged In Hardware Fault System
CP001:24 Service 1 Stopped Hardware Fault System
CP001:25 Service 2 Stopped Hardware Fault System
CP001:26 Service 3 Stopped Hardware Fault System
CP001:27 Service 4 Stopped Hardware Fault System
CP001:28 Reserved * *
| | | | | | | |
CP001:64 Reserved * *
