13.0 Technical Specicaons
The following technical specicaons are important and vital to the correct operaon of the
Protégé® SE Integrated System Controller. Failure to adhere to the technical specicaons will
result in any warranty or guarantee that was provided becoming NULL AND VOID.
Integrated Control Technology connually strives to increase the performance of its products and
as a result the specicaons may change without noce. It is recommended that you always
consult www.incontrol.co.nz for the latest documentaon and product informaon.
Operang Voltage 15.5 to 16.5VAC, 50-60Hz @ 40VA (Max)
Operang Current 280mA (Typical)
Total Combined Current 1.8A (Max)
DC Output (Auxiliary) 700mA (Typical) 1.1A (Max) Electronic Shutdown at 1.1A
B1/B2 DC Outputs (Connuous) 8 Ohm 20W Siren or 700mA (Typical)
B1/B2 DC Outputs (Inrush) 1000mA
Baery Charging 350mA/700mA
Baery Low 11.2VDC
Baery Restore 12.5VDC
Electronic Disconnecon 8.76VDC
Communicaon (Ethernet) 1x 10/100Mbps Ethernet Communicaon Link
Communicaon (Serial) 1x Isolated RS-485 Communicaon Interface Port 12VDC @ 28mA. (Input)
Communicaon (Modem) 1x 2400bps Modem Communicaon
Readers (Standard Mode) 2x Wiegand or clock data readers providing one Entry/Exit Door or two
Entry/Exit only Doors.
Readers (Mulplex-reader Mode) 4x Wiegand Readers (connected in Mulplex Reader mode) providing any
combinaon of Entry or Exit for two Doors.
Zone Inputs (System Zones) 16x High Security Monitored Zone Inputs
Tamper Input Dedicated Hardware Tamper Input
PGM Outputs 6x 50mA (Max) Open Collector Output for reader LED and beeper or general
funcons.
Status Output 1x 50mA (Max) Open Collector Output
Operang Temperature 0˚ to 55˚C (41˚ to 131˚F)
Storage Temperature 10˚ to 85˚C (14˚ to 185˚F)
Humidity 0% to 85% (non condensing)
Dimensions (L x W x H) 234 x 183 x 35mm (9.21 x 7.20 x 1.37”)
Weight 790g (27.86oz)
The size of conductor used for the supply of all power to the Protégé® SE Integrated System Controller should be
adequate in size to prevent voltage drop at the terminals of no more than 5% of the rated voltage. Specicaons are
subject to change without noce, please visit www.incontrol.co.nz for updated informaon.
!
The total combined current including operang current, charging current, DC
Output (Auxiliary), B1 and B2 must be limited to a maximum of 1.8A.
