3.0 Mounng
The Protégé® SE Integrated System Controller is supplied as a PCB only (Printed Circuit Board). It
is recommended that the gear plate style enclosures be used where possible, as this provides the
best mounng and installaon soluon as well as the required cable entry and
terminaon space.
When installing the Protégé® SE Integrated System Controller ensure that there is adequate
clearance around all sides of the cabinet enclosure and air ow to the vents of the enclosure are
not restricted.
It is recommended to install the Protégé® SE Integrated System Controller in a locaon that will
facilitate easy access for wiring. It is also recommended that the Protégé® SE Integrated System
Controller is installed in electrical rooms, communicaon equipment rooms, closets or in an
accessible area of the ceiling.
Step 1
Insert the plasc standos in to the locaons to mount the PCB board.
Step 2
Calculate the locaon and posion of the cabinet enclosure and mark the holes for the keyhole
points in the top le and right locaons. This will allow you to screw in the screws and then hang
the box on them adjusng the locaon to suit.
Step 3
Ensure a solid xing point and screw in the two screws. Before ghtening the top screws insert the
tamper bracket in the slot provided on the right side of the cabinet enclosure.
Step 4
Fix the cabinet enclosure securely using the remaining mounng holes on the boom le, right
and centre of the cabinet enclosure.
Step 5
If you are extending the Protégé® SE Integrated System Controller by the addion of a
communicaons module or memory interface insert the 4 extended nylon standos through the
rear of the Protégé® SE Integrated System Controller.
Step 6
Insert the PCB in to the cabinet enclosure and mount using the plasc standos inserted during
step 1.
!
It is recommended to install the cabinet enclosure when the circuit board is not
installed on the plasc standos as this will reduce the risk of damage caused by
debris during the installaon.
4
