The isolated communicaons interface on the Protégé® SE Integrated System
Controller uses full galvanic isolaon to prevent ground loop noise and cross phase
ground dierenal. This is a very important feature of the product family and the
correct connecon of power to this isolated secon will ensure the correct
operaon of the communicaons network.
13.1 Current and Validaon Example 1
The example shown below refers to the specicaon’s table needed to help ensure the correct
installaon of the Protégé® SE Integrated System Controller. Specicaons have to be validated to
ensure that individual maximum currents and total combined current are not exceeded.
External Devices Connected to Panel
4x EDGE PIR Moon Detectors (Z1 to Z4)
1x 15W Siren (500mA @ 13.8VDC)
Current Consumpon
Total Combined Current Available 1.8A (1800mA)
Operang Current 280mA (Typical)
Baery Charging 350mA (Standard Current Charging)
DC Output (Auxiliary) 4x EDGE PIR Moon Detectors @ 15mA each (Total 60mA)
Siren on Bell 2 Output 500mA
Total Consumpon 1.19A (1190mA)
Validaon
Is the total DC Output (Auxiliary) current less or equal to 700mA? Yes, it is 60mA
P
Is Bell 1 current less or equal to 700mA? Yes, it is 500mA
P
Is the total consumpon less or equal to 1.8A (1800mA)? Yes, it is 1.19A (1190mA)
P
