12.0 System Capacies
The Protégé® SE Integrated System Controller can be proled to allow a comprehensive soluon
that allows opmal performance to be achieved in any installaon.
Standard Access Elevator School Storage Automaon Apartment
Users 2000 10000 2000 2000 500 2000 2000
User Names 2000 2000 0 2000 500 2000 2000
Events 2000 4000 2000 4000 4000 1000 2000
Areas 32 32 64 64 128 64 248
Doors 16 128 64 16 16 64 4
Keypad Modules 32 16 8 8 8 32 48
Analog Expanders 8 8 8 8 8 16 8
Zone Expanders 16 8 4 32 64 8 4
Reader Expanders 8 64 32 16 8 32 4
Output Expanders 8 8 8 8 32 8 2
Zone Inputs 464 720 368 688 624 528 1104
Trouble Zone Inputs 704 1408 800 768 832 1088 2224
PGM Outputs 420 772 468 452 772 612 1108
PGM Groups 128 128 28 28 248 128 128
Area Groups 32 32 64 64 248 64 248
Menu Groups 16 16 16 16 16 16 16
Door Groups 128 248 28 32 16 16 16
Keypad Groups 32 16 8 8 8 8 8
Access Levels 128 248 248 32 248 64 16
Zone Types 128 128 32 28 248 64 16
Door Types 8 8 8 8 8 8 4
Services 8 8 8 8 4 8 4
Phone Numbers 16 16 16 16 8 8 8
Schedules 128 248 48 28 64 32 32
Holidays 32 32 32 32 32 32 8
Daylight Saving Adjustment Sengs 1 1 1 1 1 1 1
Automaon Points 32 32 32 32 16 248 8
Panel Conguraon Informaon 1 1 1 1 1 1 1
Area Names 32 32 64 64 128 64 248
Access Level Names 128 248 48 32 248 64 16
Zone Type Names 64 64 32 28 248 16 16
Zone Names 464 720 68 88 1136 28 1104
Home Names 16 8 16 16 16 16 16
Door Names 16 128 16 16 16 4 4
Door Type Names 8 8 8 8 8 4 4
Area Group Names 64 32 64 64 248 248 248
Menu Group Names 16 16 16 16 16 16 16
Keypad Group Names 8 8 8 8 8 4 4
Phone Number Names 8 8 8 8 8 8 8
Schedule Names 64 248 32 32 64 32 32
Door Group Names 16 248 16 16 16 4 4
Floor Group Names 32 32 28 16 16 16 4
PGM Names 420 16 16 16 16 16 4
Floor Names 128 128 28 0 0 0 0
Elevator Names 8 8 8 16 8 0 0
Elevator Floor Groups 32 32 28 16 8 0 0
Elevator Cars 8 8 16 8 8 8 0
Elevator Floor 1024 1024 48 24 1024 1024 0
Programmable Funcon 64 64 32 32 128 128 0
Elevator Car Groups 8 8 16 8 8 8 0
Elevator Car Group Names 8 8 16 8 8 8 0
Variable 248 248 248 248 248 248 248
Bit variable 248 248 248 248 248 248 248
Door Schedules 0 0 0 0 0 0 0
Floor Schedules 0 0 0 0 0 0 0
