4.3 AC Power
The Protégé® SE Integrated System Controller should be supplied by a dedicated electrical power
source rated for a minimum 10Amp load and have a dedicated circuit breaker. Do not use a switch
controlled breaker or a switched electrical point to supply electrical power. Connect the primary of
a 16VAC, 50/60Hz, 40VA transformer to the electrical circuit and run the secondary to the AC Input
on the Protégé® SE Integrated System Controller terminals.
Specic regional regulaons may allow the transformer to be mounted inside the cabinet
enclosure. In this case wire the electrical circuit to the electrical terminaon point inside the
cabinet enclosure and the secondary wires of the transformer to the AC Input on the Protégé® SE
Integrated System Controller. The earth wire should be routed to the terminal on the Protégé® SE
Integrated System Controller when using an internal transformer.
!
Terminaon of wiring to the Protégé® SE Integrated System Controller while power
is applied or the baery is connected may cause serious damage to the Protégé®
SE Integrated System Controller and will VOID ALL WARRANTIES OR GUARANTEES.
Power the unit only aer all wiring, conguraon and jumper sengs are
completed.
Figure 3 - AC Power Connecon
AC AC B+ B- ST TP TP
Transformer
Mains Input
