10.0 Mechanical Diagram
The mechanical diagram shown below outlines the essenal details needed to help ensure the
correct installaon of the Protégé® SE Integrated System Controller.
Figure 26 - Mechanical Diagram
16V AC Input
Isolated COMMS
Mounng Holes
350mA/700mA Jumper
EOL Jumper
Baery Input
Cabinet Tamper Input
Bell/Siren Outputs
PGM 3/4 Outputs
Zones 1 to 4
Fault/Status LED
Coin Cell Baery
Zones 5 to 8
Zones 9 to 12
Reader Port 1
Reader Port 2Zones 13 to 16
RS-485 Network
Telephone Dialer
Cong Switch
10/100 Ethernet
Ethernet Status LEDs
Expansion Interface
Part Number
