Tsunami QB-8100 Series (100 Mbps/5 Mbps Models) Installation and Management Guide 120
NOTES:
• IGMP Snooping functionality is available both in End Point A and End Point B.
• QB 8100 supports only passive IGMP Snooping.
• IGMP versions V1,V2 and V3 are supported.
• End Point A/End Point B add maximum 64 Multicast groups in the Snooping table.
4.10.1 IGMP Snooping Configuration
To configure IGMP Snooping:
1.Click ADVANCED Configuration > IGMP Snooping. The IGMP snooping screen appears as shown below.
Figure 4-64 IGMP Snooping
2. Enter the appropriate parameters in the IGMP Snooping Table. See the following table that lists the parameters and their
descriptions.
3.Click OK. To apply the changes, click COMMIT.
Parameter Description
IGMP Snooping Status This parameter is used to Enable/Disable the IGMP Snooping
feature for the device. This feature is supported only in bridge
mode. By default, IGMP Snooping Status is disabled.
IGMP Membership
Aging Timer
This parameter represents the time after which the IGMP
multicast group age-outs or elapses. It ranges from 135 to 635
sec. The default IGMP Membership Aging Timer is 260 sec.
IGMP Router Port
Aging Timer
This parameter represents the time after which the IGMP router
port age-outs or elapses. It ranges from 260 to 635 sec. The
default IGMP Router Port Aging Timer is 300 sec.
IGMP Forced Flood If you select Yes, all the Unregistered IPv4 multicast traffic (with
destination address which does not match any of the groups
announced in earlier IGMP Membership reports) and IGMP
Membership Reports will be flooded to all the ports. By default,
IGMP Forced Flood is set to No.
